VHF Narrow Band Receiver System
Dual Frequency Design (Channel A/B)
High Signal/Noise Ratio Performance
Broad Frequency Response Range & Low Distortion
Independent Adjustable Volume Control
Dual Independent Channel Antennas
RF Signal and AF Signal LED Indicators
Radio Frequency and Audio Frequency
Includes (2) Handheld Microphones
System Receiver:
Channel Frequency: 174~216MHz
Sensitivity: -95dBm (S/N:12dB)
RF Image Rejection:-75dB
Audio Dynamic Range: 95dB
T.H.D.: <1%
Frequency Stability: ±0.002%
S/N Ratio:>70dB
Neighboring Channel / Interference:>70dB¬¬
Frequency Response: 50Hz~15KHz ±3dB
Power: AC 120V, 60Hz
Receiver Dimensions (L x W x H): 8.07” x 5.75” x 1.64”
Microphones:
Carrier Frequency:174~216MHz
RF Power Output:>13dBm
Modulation Degree:>30KHz
Power Current: <110mA
Frequency Stability: ±0.002%
Harmonic at Higher Degree: <60dB
Modulation Pattern: FM
Battery Powered: Requires 2 x ‘AA’ Batteries
Brand NEW
1 Year Manufacture’s Warranty
