Aluminum Bearing Block With Bushing

The Aluminum Bearing Block w/ Bronze Flange Bushing is a drive pipe support made from extruded 6061-T6 US aluminum. Fits 1 1/2 in. OD drive pipes. It mounts before and after the cable winder.It rests in between (2) aluminum channels. The bottom of the block secures through the body of the aluminum beam using a bolt, washers, and nut. The drilled-out housing has (3) 9/16 in. mounting holes for the mounting bolt. The flange bushing secures inside the aluminum housing. The bronze flange bushing has a 1 7/8 in. bore. The aluminum housing has a grease channel drilled through. Allows for easy greasing of the bushing against the block. Includes factory-installed 1/4 in. grease fitting.
